GAS ANALYZER

Gas AnalyzersCHLORINE METER The Model 1205B Gas Analyzer accurately measures the concentration of carbon monoxide (CO) and carbon dioxide (CO2) in a duct or space. The Gas Analyzer displays the measurement on a two line digital LCD display with backlight. The unit’s memory stores up to 255 sets of readings that are logged manually or auto-logged with 1 to 10 minute intervals. Besides measurement recording, Model 1205B can provide a summary of average and maximum levels reached during recording. Results then can be printed via an optional infrared printer. Model 1205B includes batteries, 120V power supply, protective rubber boot with integral magnet, sampling probe, and a canvas carrying case.Features:Ranges:CO: 0 to 1000 ppm, overflow 2000 ppmCO2: 200 to 4000 ppm, overflow 9999 ppm.Resolution: 1 ppmAccuracy:CO: ±5 ppm<100 ppm; ±5%>100 ppm; ±10%>1000 ppmCO2: ±20 ppm<400 ppm; ±5%<4000 ppm; ±10%>4000 ppmDual LCD displayCE approvedWhat's In The Box:(5) Batteries(1) 120V power supply(1) Protective rubber boot with integral magnet(1) Sampling probe(1) Canvas carrying case

Gas AnalyzersGAS ANALYZER TPI 735A Combustible Gas Leak DetectorDesigned to quickly and accurately measure natural and propane gas leaks, as well as carbon monoxide concentrations.735A: Measure Leak, LEL and CO. Designed to quickly and accurately measure natural and propane gas leaks, as well as carbon monoxide concentrations. Sensit Gold instruments are Approved UL913, For Class 1, Division 1, Groups C and D Hazardous locations when used with alkaline batteries.The Sensit Gold product line is designed to detect combustible gases, oxygen content. and toxic gases when so equipped with the available sensors. Each model of the Sensit Gold provides specific detection features based upon available sensor options.Applications:Gas Leak Survey/InvestigationsConfined Space MonitoringGas Emergency InvestigationsVessel TestingFeaturesInternal PumpWater/Dust FilterPush Button OperationField CalibrationDate/Time DisplayCalibration AlertOperation MemoryCalibration MemoryInfrared DownloadAudible/Visual AlarmsBacklit LCDProgrammable Auto Shut Off

Gas AnalyzersGAS ANALYZER TPI 716 Flue Gas Combustion Analyser - Kit 5 DetailsThe most comprehensive TPI 716 kit available, this bundle comes with all standard accessories plus an infrared printer, 2 x pipe clamp probes, a CPA1 probe kit and a gas sniffer! In other words, it comes with absolutely everything you'll need for flue analysis.The TPI 716 is a fast-response, professional-grade flue gas analysis tool compatible with boilers powered by natural gas, LPG, light oil, heavy oil, bituminous coal, anthracite coal, coke, butane, wood and bagasse.With built-in datalogging capabilites, the 716 can capture results for easy recall at a later date. This information can either be sent to a PC via a USB cable or can be wirelessly printed using the infrared printer (included with this kit).Absolutely every aspect of a boiler's operation can be checked with the 716; it features a built-in differential manometer for pressure measurements, a built-in thermometer for differential temperature measurements and can also test excess air, efficiency, oxygen levels, CO/CO2 ratio and much more.TPI 716 Flue Gas Combustion Analyser Key FeaturesLarge size, easy-to-read 4 or 8 line graphical display - no need to scroll through measurements - see them all at once!Measure O2 (oxygen), CO (carbon monoxide) and flue temperatureCalculate efficiency and excess airCO and CO/CO2 ratio calculationsBuilt-in CO analyser detects carbon monoxide levels in ambient airDifferential manometer built-in with ±150mBar range (0.01mBar resolution)Dual type K thermocouple differential thermometer built-in30 second countdown function for combustion readings speeds up testing timeEnhanced let-by and tightness testing with timed start, stop and differential pressure readingsMenu-driven user interface - easy to navigate to different functionsCO built-up test - quickly prove or disprove CO levelsSimultaneously measure pressure and combustion readingsLarge capacity pump with visible flow rate on screen - constantly monitored to prevent damage and downtime10000ppm CO sensor - ensures that the analyser won't be damaged if exposed to high levels of CODatalogging with date and time stampingCommunicate to a PC via USB connectionPush-on fittings for fast and easy use6 year warranty included as standardWhat's Included?TPI 716 Flue Gas Combustion AnalyserCombustible Gas Leak ProbeRubber Boot (Installed On Analyser)Soft Carrying CaseFlue Sampling ProbeIn-Line Filter/Water Trap (Installed on Flue Probe)Disc Water Filter (Installed in Water Trap)Temperature ProbeBattery ChargerMini Pump Protection Filter AssemblyRemovable Exhaust SpigotPressure Tubing2 x Static Pressure Tips2 x ¼" barbed to 1/8" NPT FittingGas Valve AdapterInstruction ManualInfrared Printer2 x Pipe Clamp Temperature ProbesCPA1 Probe KitPlug-In Gas Sniffer

Gas AnalyzersAKUN SAYASemua Kategori Mesin & Peralatan IndustriAlat Uji & UkurGas AnalyzerTPI 716 Flue Gas Combustion Analyser - Kit 4Update Terakhir:10 / 10 / 2019Min. Pembelian:1 UnitTAMBAH KE FAVORITHarga CALLBagikan:Perhatian !Perusahaan ini terdaftar sebagai Free Member. Untuk menghindari hal-hal yang tidak diinginkan,harap berhati-hati ketika melakukan transaksi. Indonetwork tidak melakukan verifikasi alamat dan dokumen untuk keanggotaan Free Member. Kami tidak bertanggung jawab apabila terjadi hal-hal yang tidak diinginkan.DESKRIPSI PRODUKTENTANG PERUSAHAANDetail TPI 716 Flue Gas Combustion Analyser - Kit 4GAS ANALYZER TPI 716 Flue Gas Combustion Analyser - Kit 5 DetailsThe most comprehensive TPI 716 kit available, this bundle comes with all standard accessories plus an infrared printer, 2 x pipe clamp probes, a CPA1 probe kit and a gas sniffer! In other words, it comes with absolutely everything you'll need for flue analysis.The TPI 716 is a fast-response, professional-grade flue gas analysis tool compatible with boilers powered by natural gas, LPG, light oil, heavy oil, bituminous coal, anthracite coal, coke, butane, wood and bagasse.With built-in datalogging capabilites, the 716 can capture results for easy recall at a later date. This information can either be sent to a PC via a USB cable or can be wirelessly printed using the infrared printer (included with this kit).Absolutely every aspect of a boiler's operation can be checked with the 716; it features a built-in differential manometer for pressure measurements, a built-in thermometer for differential temperature measurements and can also test excess air, efficiency, oxygen levels, CO/CO2 ratio and much more.TPI 716 Flue Gas Combustion Analyser Key FeaturesLarge size, easy-to-read 4 or 8 line graphical display - no need to scroll through measurements - see them all at once!Measure O2 (oxygen), CO (carbon monoxide) and flue temperatureCalculate efficiency and excess airCO and CO/CO2 ratio calculationsBuilt-in CO analyser detects carbon monoxide levels in ambient airDifferential manometer built-in with ±150mBar range (0.01mBar resolution)Dual type K thermocouple differential thermometer built-in30 second countdown function for combustion readings speeds up testing timeEnhanced let-by and tightness testing with timed start, stop and differential pressure readingsMenu-driven user interface - easy to navigate to different functionsCO built-up test - quickly prove or disprove CO levelsSimultaneously measure pressure and combustion readingsLarge capacity pump with visible flow rate on screen - constantly monitored to prevent damage and downtime10000ppm CO sensor - ensures that the analyser won't be damaged if exposed to high levels of CODatalogging with date and time stampingCommunicate to a PC via USB connectionPush-on fittings for fast and easy use6 year warranty included as standardWhat's Included?TPI 716 Flue Gas Combustion AnalyserCombustible Gas Leak ProbeRubber Boot (Installed On Analyser)Soft Carrying CaseFlue Sampling ProbeIn-Line Filter/Water Trap (Installed on Flue Probe)Disc Water Filter (Installed in Water Trap)Temperature ProbeBattery ChargerMini Pump Protection Filter AssemblyRemovable Exhaust SpigotPressure Tubing2 x Static Pressure Tips2 x ¼" barbed to 1/8" NPT FittingGas Valve AdapterInstruction ManualInfrared Printer2 x Pipe Clamp Temperature Probes

Gas AnalyzersGAS ANALYZER Compliance testing and combustion troubleshooting is now easier when you use the new testo 350. This new portable emission analyzer provides the highest accuracy, ultra-rugged construction, easy operation and innovations in measurement technology to set a new standard in portable analyzers.testo 350 Emission Analyzer: A New Standard in ServiceabilityThe new testo 350 raises the bar in testing serviceability. Its new design allows for routine service and " plug and play " convenience – no tools needed. Simply click out the sensor, or chiller filter, or pump – it' s that simple.Other features include: Easy-access service openingThermally-separated sensor chamberPlug and play " smart sensors " for easy field replacementAutomatically monitored condensate trap with CO2 upgradeCooling loop designed to isolate electronics and sensors from harsh ambient conditionsAutomatic flow-controlled sampling pump so a constant sample flow is maintainedtesto 350 Control Unit and Analyzer BoxThe new testo 350 control unit is small in size, but big in capability. The interface provides a variety of field configurations that makes testing easier to perform, faster to setup and safer for you. As soon as you pick up the testo 350 analyzer box, you will know it is rugged, but you will be surprised at its light weight. Don' t let that weight fool you however. It is packed with the latest in measurement technology. The analyzer box contains the sensors, pumps, electronics and of course testo' s analyzer know-how.Analyzer BoxUp to six sensors can be installed and additional parameters can be swapped out in secondsIntegrated circuitry for a better response, easier calibrations and unmatched versatilitySensor interference filters and smart diagnostics assure sensor accuracy, increased sensor life, and quick replacementAdvanced continuous temperature compensation eliminates drift due to changing ambient conditionsAutomatic or user-defined dilution systems dramatically increase testing range and accuracyIndividual sensor temperature monitoring and temperature compensationIncreased thermal stability due to new housing design and insulating sensors from heat and electronicsGas paths built with non-reactive materials necessary for the highest level of accuracyPatented high velocity sample lines increases response time and maintains sample integritySample conditioning utilizing thermoelectric cooling to remove moisture and provide a dry sample resulting in a better measurement and is required by most testing protocolControl UnitEasy to read measurements, whether you are standing at the control panel or sitting in your truckControl the analyzer box via Bluetooth up to 300 feet away or hard-wired up to 1000' s of feet awayStore your data until it is convenient for downloadRealize the power of real time graphics on the 350' s brilliant HD color displayMeasurements of velocity and flow, and the calculation of ton/ year or lbs/ hr, are performed with easeIncrease accuracy by eliminating long sample lines, long response times, and the higher potential for sample absorptionWhen complete, click control unit face down for protection during transportPacking List: 350 Analyzer Box350 Control UnitO2 Sensor ( 0 to 25% ) CO Sensor: Low Range ( 0 - 500 ppm, 0.1 res.) NO Sensor: Low Range ( 0 - 300 ppm, 0.1 res.) NO2 Sensor ( 0 to 500 ppm) CO Dilution systemCO Release code for dilution systemGas conditioningFresh Air Valve16' data bus cableCarrying strapBasic Excel softwarePrinter paper ( 6 rolls) Particle filters ( 20 pack) Pelican case with insertEngine emission sampling probe; 13 " 2000° F w/ 7' teflon lineMini ambient air probe

Gas AnalyzersGAS ANALYZER The testo 340 is the ideal tool to confirm proper set-up and to identify emission problems before they get serious.  Oxygen is the base sensor in all Testo 340 Analyzers.  Simply add one, or up to three sensors for your specific job.This combustion analyzer can be configured in many ways for commissioning commercial boilers, testing engines in midstream gas pipelines, tuning industrial burners in refineries, or cement or glass or any other combustion system that requires high confidence, so you can make the proper control adjustments. Four (4) gas flexibility – O2 comes standard, then choose what’s needed for your combustion tuningSelect the industrial CO sensors (0-10,000 ppm with a 50,000 ppm upper dilution range) for tuning standard systems or swap out and use the CO low range sensor (0-500 ppm) for critical low range carbon monoxide limits.  Add the NO and NO2 sensors for a NOx reading for tuning boilers or engines.  You can even field swap the standard NO sensor for the NOlow sensor and have 0.1 ppm NOx resolution for tighter combustion control.  Add the SO2 sensor to monitor sulfur laden fuels or additives.   We have a variety of kits configured for specific combustion tuning applications.   The analyzer Kits are configured to deliver the best performance whether you are testing a boiler or burner, stationary or mobile engine tuning, or pre-compliance testing. Analyzer Kits - 4 Configured for typical combustion needsTwo gas: (O2, CO) standard combustion kitThree gas: (O2, CO, NO) combustion kit for Boilers & BurnersThree gas: (O2, CO, NO) Engine Testing KitSingle gas upgrade with O2 - Add what you need.Built to lastLong life-time CO and NOx sensors (up to 5 years) make cost of ownership the best in market.  Field exchangeable sensors allow greater flexibility.The automatic dilution (range extender) factor-5x increases the CO range to 50,000 ppm.  The analyzer will calculate and display the corrected values.  User defined setpoints means you can extend the CO sensor life and maintain accurate measurements.Rubberized shock resistant housing and clear over-plate protects analyzer and display screen. Magnets on back housing allows you to mount the analyzer for easier viewing.Beneficial features and useful optionsThe back-lit display is easily customized, can display from 4 to 8 lines, or show a variety of measurement options, such as PPM values or as MMBtu/hr. shows measurementsImportant calculation including, combustion efficiency, excess air calculations, corrected NOx and corrected CO values.  18 fuels to choose fromOnboard Diagnostics – Simple Push the I button and scroll down to see instrument status.Draft and differential pressure and Mass Emission calculations (i.e. lbs./hr., tons/yr) with any Pitot tubeOptions:Hose extensions -9-foot quick connect extensions with integrated thermocouple means you can extend the hose to 25 feet.  Simply disconnect them for easier, less bulky transport.Industrial sample probes from 3 feet to 9 feet long and from 1,112 °F to 3,200 °FInfrared printereasyEmission Software - for real time data loggong or downloading from instrument memory Delivery Scopetesto 340 flue gas analyzer, calibration certificate, shoulder strap, O2 sensor, and integrated flow and pressure difference measurements.PLEASE NOTE: Your testo 340 must be fitted with a second gas sensor for it to work. Up to three additional sensors can be fitted.

Gas AnalyzersGAS ANALYZER The 320 comes with fitted O2 and CO sensors and can be used for comprehensive flue gas analysis in a wide variety of different systems. It’s ideal for ensuring that things are correctly installed, legal limit values are maintained and malfunctions are sorted as quickly as possible. This product is a truly all-encompassing tool for analysing different flue aspects. It can be used to carry out draught measurements, pressure measurements, O2 measurements, CO measurements without/with H2 compensation, carry out efficiency testing, exhaust gas loss, CO2 determination (digital calculation from O2), option COlow measurement (H2-compensated) and more! Each different testing procedure or function is easily accessible using the included accessories and menu structure of the device, and each different parameter has a wide measurement range and high accuracy for delivering the best results possible.The major inclusion in this kit is the Testo IRDA printer, a device which allows users to print out stored data using infrared wireless technology. If you need quick reports in a hurry, this product is ideal for ensuring you can give documentation to the person who needs it without having to worry about using a PC to get itFeatures:Probe filters are easily exchangeableCan store up to 500 measurement protocols in built-in memoryBuilt in magnets allow attachment to metallic surfacesLithium ion rechargeable battery gives eight hours running time (rechargeable via USB)Automatic sensor zeroingTÜV-tested according to EN 50379, Parts 1-3Sensor monitoring displays sensor status with traffic light systemHigh resolution graphical display for easy navigation and results viewingTemperature measurements between a range of -40 to 1200°CDraught measurements between range of -9.99 to 40hPaPressure measurement from 0 to 300hPaO2 measurement with range of 0 to 21% vol %CO measurement (without H2 compensation) – 0 to 4000ppmCO measurement (with H2 compensation) – 0 to 8000ppmEfficiency testing (Eta) with range of 0 to 120%Exhaust gas loss with range of 0 to 99.9%CO2 determination digital calculation from O2 with range of 0 to CO2 maxIncludes:Testo 320 Flue Gas AnalyserIntegrated O2 and CO SensorsTesto IRDA PrinterHard CaseRechargeable BatteryUSB Cable180mm Flue Gas Probe5 x Replacement Filters

Gas AnalyzersGAS ANALYZER Features:Integrated printerPreliminary and main test on gas pipesPressure drop test on water pipes (high pressure measurement up to 30 bar)Fast measurement of amount of gas leaking according to DVGW-TRGI '86/96 / VP 952Efficient detection of gas leaks using the testo 316-1Analysis software to show course of measurementServiceability test on gas pipesData recording for testing pressure regulatorAnalysis with PC softwarePreliminary and main test on gas pipesSingle valve block for blocking off the pipeTest pump for generating test pressureLeak detection spray for spraying on gas pipe, bubbles indicate leaking pointsWith efficient measurement due to absolute pressure compensation the testo 314 independently compensates fluctuations in absolute pressure during volume flow measurement via absolute pressure compensation.Zeroing phase for connected pipeTo determine ΔP efficiently and quickly, zeroing to ambient air pressure takes place while the measurement is in progress, thus eliminating interruptions and removal of pipes.Measuring using standard test pressure compensation with feeding unit.The flow test which is independent of gas mains, has the advantage that pressure fluctuations in pipes can be compensated. The built in flow pressure controller (gas bubble with gas feeding unit) compensates for fluctuations. The finely adjusted value is displayed along with the leakage amount.Includes:Pressure meterBuilt-printer1000 mbar to +1000 mbarSpecifications:Pressure Measurement range: 0 to 1000 mbarResolution:  0.1 mbarAccuracy:  ±0.5 mbar; ±3% of mvVolume flow measuring range:  0 to 8 l/hResolution: 0.1 l/hAccuracy: ±0.1 l/h; ±5% of mvBattery life: > 5 hDimensions: 252 x 115 x 58 mmWeight :  Approx. 728 g

Gas AnalyzersGAS ANALYZER SKF TMSU Series: The SKF TMSU 1 ultrasonic leak detector is a high quality, user friendly, sensitive instrument enabling the detection of air leaks by means of ultrasound. Leaks are caused by fluid flowing from a high pressure environment to a low pressure environment, creating turbulence. The turbulence generates high frequency sounds (so called ultrasound) that can be detected by TMSU 1 air leak detection equipment. The sensitive piezoelectric crystal in the sensor allows the operator to quickly guide the instrument to the loudest point which helps locate the leak location. The SKF TMSU 1 includes an ultrasonic air leak detector, headset, rubber nozzle and batteries, all supplied complete in a sturdy carrying case. Lightweight compact design makes it easy to operate with one hand. By identifying air leaks and fixing them, energy consumption is significantly reduced. Excellent quality headset for optimum sound quality even in very high-noise environments, also act as ear defenders. Note: Wide operating temperature suitable for diverse industrial environments

Gas AnalyzersGAS ANALYZER A full-blood analyzer despite compact size. This flue gas analyzer can be fitted with up to 3 electrochemical sensors. This is an attractive alternative to other, larger flue gas analyzers on the market. Is especially suited to short-term measurements on small burner systems. Designed according to EN50379.Technical dataSize 245 x 116 x 45 mmWeight 0.6 kgProbe length 150 mmLength of gas line 2 mIn line filter in-line, Filter 20 µ mDisplay LCD Graphic display 36 x 66 mmPower supply 6 V ( 4 x AA) Battery, or external power supply 9 VDCInterface RS232C for external computerIR connection for external printerGas pump Membrane pumpClock/ calendar Integrated clock/ calendarOperating temperature 10 ° C ÷ 50° CStorage temperature -20 ° C ÷ + 55 ° C▪  Parameters :   O2     : 0 - 25%   CO    : 0 - 20,000 ppm   NO    : 0 - 1000 ppm   CO2  : 0 - 25% (Calculated)▪  Display : LCD graphic display 36 x 66 mm▪  Gaspump : Membrane pump▪  Flue Gas Temperature : -10 to 1,000 ˚C▪  Processing and presentation of measuring data :   All results shown on display   Averaging of all measured values. Averaging time: 2, 10,   20, 30, 60, 120, 180 seconds   Graphical presentation of all measured values as diagram   Storage for 16 measurements - "measure now, print later"   Powerful PC program for flue gas analyzer settings and   data communication▪  Size / weight : 228 x 72mm / 0,6 kg▪  Probe with condensate trap and filter▪  Probe length 150 mm▪  Length of gas line 2 m
